产品介绍规格型号
型号表示 |
链条本体尺寸 |
隆德链号 | 节距 | 滚子直径 | 内节内宽 | 销轴直径 | 销轴长度 | 链板 | 极限拉伸载荷 | 约重 | 组件的链节数 | 可使用的温度范围 | |||||
P | R | W | D | L1 | L2 | L | 厚度 | 厚度 | 宽 H | 宽 h | Q | ||||
T1 | T2 | ||||||||||||||
mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/kgf | kg/m | LJ | ℃ | |
LD08B | 12.70 | 8.51 | 7.75 | 4.45 | 8.4 | 10 | 18.6 | 1.6 | 1.6 | 12 | 10.4 | 12.9/1320 | 0.70 | 240 | -10℃-150℃ |
LD10B | 15.875 | 10.16 | 9.65 | 5.08 | 9.55 | 11.3 | 20.8 | 1.5 | 1.5 | 14.7 | 13.7 | 15.7/1600 | 0.95 | 192 | -10℃-150℃ |
LD12B | 19.05 | 12.07 | 11.68 | 5.72 | 11.1 | 13 | 24.4 | 1.8 | 1.8 | 16.1 | 16.1 | 22.1/2250 | 1.25 | 160 | -10℃-150℃ |
LD16B | 25.40 | 15.88 | 17.02 | 8.28 | 17.75 | 19.95 | 39.3 | 4.0 | 3.2 | 21 | 21 | 6.0/6120 | 2.70 | 120 | -10℃-150℃ |
2nLWSK附件尺寸 |
隆德链号 | C1 | NW | O | XS | KW | 一个附件的附加重量 |
mm | mm | mm | mm | mm | kg | |
LD08B-2nLWSK1 | 13.1 | - | 4.9 | 20.7 | - | 0.01 |
LD10B-2nLWSK1 | 16.6 | - | 5.0 | 23.6 | - | 0.012 |
LD12B-2nLWSK1 | 17.6 | - | 5.5 | 25.75 | - | 0.018 |
LD16B-2nLWSK1 | 26.0 | - | 8.1 | 36.7 | - | 0.06 |
LD08B-2nLWSK2 | 13.1 | 24.6 | 4.9 | 20.7 | 12.7 | 0.01 |
LD10B-2nLWSK2 | 16.6 | 30.0 | 5.0 | 23.6 | 15.9 | 0.012 |
LD12B-2nLWSK2 | 17.6 | 34.8 | 5.5 | 25.75 | 19.1 | 0.018 |
LD16B-2nLWSK2 | 26.0 | 46.0 | 8.1 | 36.7 | 25.4 | 0.060 |
